Supports customization with a processing capacity of up to 15900 CFM (cubic feet per minute).
The 1130 SCFM refrigerated air dryer (air cooled) is a high-capacity, energy-efficient solution designed to eliminate moisture from compressed air systems in demanding industrial environments. With a robust air-cooled refrigeration system and a processing capacity of 1130 SCFM, this dryer delivers consistent performance and reliable dew point control to protect downstream equipment and ensure production continuity.
Whether you’re operating in a manufacturing plant, automotive facility, or heavy-duty processing site, the 1130 SCFM refrigerated air dryer (air cooled) guarantees optimal air quality while reducing maintenance costs and energy waste.
✅ High Processing Capacity: Handles compressed air volumes up to 1130 SCFM, ideal for large-scale systems.
✅ Air Cooled System: Eliminates the need for water cooling infrastructure, reducing installation and operational costs.
✅ Stable Dew Point: Maintains a reliable pressure dew point between 2–10°C (35.6–50°F), preventing condensation and corrosion.
✅ Efficient Refrigeration Circuit: Equipped with a durable scroll or rotary compressor for low energy consumption.
✅ User-Friendly Interface: Real-time monitoring, alarms for high temperature, and system status indicators.
✅ Automatic Condensate Drain: Ensures consistent moisture discharge without manual intervention.
The 1130 SCFM refrigerated air dryer (air cooled) is engineered for performance, reliability, and long-term value.
Inlet Air Temperature: ≤ 45°C (113°F)
Ambient Temperature: 5 – 45°C (41 – 113°F)
Installation Location: Indoor, well-ventilated, dust-free environment
Power Supply: 380V / 3Ph / 50Hz (or customizable)
Refrigerant Type: R407C or R134a (environmentally friendly options)
Recommended Filters: Pre-filter and after-filter for optimal protection and air quality
| Model | 1130 SCFM Refrigerated Air Dryer (Air Cooled) |
|---|---|
| Capacity | 1130 SCFM (Standard Cubic Feet per Minute) |
| Cooling Method | Air Cooled |
| Power Supply | 380V / 3Ph / 50Hz |
| Max Operating Pressure | 10 bar |
| Pressure Dew Point | 2 – 10°C |
| Refrigerant | R407C / R134a |
| Connection Size | 3″ NPT or Flanged |
| Dimensions (L×W×H) | 1850 × 1100 × 1800 mm |
| Weight | 520 kg |
The 1130 SCFM refrigerated air dryer (air cooled) is built for durability and continuous operation in challenging conditions.
In Malaysia’s hot, humid, and high-rainfall climate, large compressed air systems are more vulnerable to condensation, water carryover, corrosion, and unstable pneumatic performance. For plants that require high-capacity air drying but prefer not to install cooling water infrastructure, the 1130 SCFM refrigerated air dryer (air cooled) is well suited for centralised compressed air systems and large-scale indoor industrial operations requiring reliable everyday moisture removal.
The 1130 SCFM refrigerated air dryer (air cooled) is suitable for applications in Malaysia such as:
– As an air treatment and gas purification manufacturer, we can meet all your compressed air quality and industrial gas needs. This includes various filtering equipment and customized air quality services.
– Our company is always ready to provide explanations. Just share your air quality requirements and we can develop the best system for you.
Need help navigating our compressed air dryer offer? We are always ready to put together the solution that best meets your needs.
The air is pure, no secondary pollution, integrated skid-mounted design, compact structure, stable dew point, remarkable water removal effect.
Stainless steel plate heat exchanger with high heat exchange efficiency and compact structure.
Independent stainless steel steam-water separator with high water separation efficiency, timely separates condensed water and other impurities from compressed air and discharges them out of the machine.
The whole machine is made of stainless steel or aluminum alloy, which will not rust and prevent secondary contamination of compressed air.
Single chip intelligent control, real-time display of evaporation temperature, including over-temperature alarm, electrical fault, high pressure alarm, low pressure alarm and other functions.
Low pressure loss: The precooler is a newly designed annular pipe structure, with three times more pipes than the traditional precooler. The sufficient cross-sectional area of compressed air further reduces the pressure difference, and the pressure loss of the whole machine is less than 0.1 bar;
Frequency conversion energy saving: Brand inverter, frequency conversion range 30Hz~90Hz, by changing the electromechanical frequency of the dryer to match the actual working conditions;
Intelligent control: Standard PLC and touch screen, intelligently control the compressor cooling capacity output by sensing the evaporation load, ensure the machine runs in the best state, and standard RS-485 communication interface.
Low pressure loss: The precooler is a newly designed annular pipe structure, with three times more pipes than the traditional precooler. The sufficient flow cross-sectional area of compressed air further reduces the pressure difference, and the pressure loss of the whole machine is less than 0.1bar;
Low dew point: The new optimized integrated three-in-one design and unique water separation design make the dew point more guaranteed;
Intelligent control: Standard PLC and touch screen, intelligently control the compressor cooling capacity output by sensing the evaporation load, ensuring that the machine runs in the best state, and standard RS-485 communication interface.
