Supports customization with a processing capacity of up to 15900 CFM (cubic feet per minute).
The 200 CFM refrigerated air dryer (air cooled) is a compact and efficient solution for removing moisture from compressed air systems. Designed for mid-sized industrial applications, this dryer ensures clean, dry air to protect downstream equipment from corrosion, contamination, and failure.
With air-cooled technology and stable dew point performance, the 200 CFM refrigerated air dryer (air cooled) offers a reliable and energy-saving approach to compressed air drying.
✅ Rated for 200 CFM: Optimized to handle air flow rates up to 200 CFM, ideal for medium-scale operations.
✅ Air Cooled Condenser: No need for cooling water — suitable for flexible installation in any plant environment.
✅ Stable Dew Point: Maintains a consistent pressure dew point between 2–10°C (35.6–50°F).
✅ Efficient Heat Exchanger: Maximizes moisture separation while minimizing pressure loss.
✅ Energy Efficient: Designed to reduce power consumption with high-performance components.
✅ Automatic Drain System: Prevents water accumulation and extends system life.
✅ Compact Design: Space-saving footprint for easy integration into existing systems.
The 200 CFM refrigerated air dryer (air cooled) combines durability and performance to meet the demands of modern compressed air systems.
Inlet Air Temperature: ≤ 45°C (113°F)
Ambient Temperature: 5 – 45°C (41 – 113°F)
Installation Location: Indoor, clean and well-ventilated environment
Power Supply: 220V / 1Ph / 50Hz (custom options available)
Refrigerant Type: R134a or R410A (environmentally friendly refrigerants)
Filtration Advice: Pre-filters and after-filters recommended for best air quality
| Model | 200 CFM Refrigerated Air Dryer (Air Cooled) |
|---|---|
| Air Capacity | 200 CFM (Cubic Feet per Minute) |
| Cooling Type | Air Cooled |
| Refrigerant | R134a / R410A |
| Max Pressure | 10 bar |
| Pressure Dew Point | 2 – 10°C |
| Power Supply | 220V / 1Ph / 50Hz |
| Connection Size | 1¼” NPT |
| Dimensions (L×W×H) | 850 × 500 × 900 mm |
| Weight | 95 kg |
The 200 CFM refrigerated air dryer (air cooled) is engineered for easy installation, consistent performance, and long service life.
In Malaysia’s hot, humid, and high-rainfall climate, refrigerated air dryers are widely used to reduce moisture in compressed air systems and help prevent condensation, rust, water carryover, and unstable pneumatic performance. For medium-scale indoor compressed air systems, a 200 CFM air-cooled refrigerated air dryer is well suited for factories and commercial operations that require reliable everyday dry air, simple installation, and stable dew point performance.
The 200 CFM refrigerated air dryer (air cooled) is suitable for applications in Malaysia such as:
– As an air treatment and gas purification manufacturer, we can meet all your compressed air quality and industrial gas needs. This includes various filtering equipment and customized air quality services.
– Our company is always ready to provide explanations. Just share your air quality requirements and we can develop the best system for you.
Need help navigating our compressed air dryer offer? We are always ready to put together the solution that best meets your needs.
This 75 CFM (air-cooled) refrigerated air dryer is a reliable and energy-efficient solution, specifically designed to remove moisture from compressed air systems. It is ideal for small to medium industrial applications, providing clean, dry compressed air with a stable pressure dew point. With its compact design and air-cooled operation, this 75 CFM (air-cooled) refrigerated air dryer ensures long-term, stable performance while minimizing maintenance requirements.
Whether you operate a workshop, packaging line, or small production facility, the 75 CFM refrigerated air dryer (air-cooled) is the perfect choice to protect your pneumatic tools and equipment from moisture-related issues.
The 25/35/50 CFM Air-Cooled Refrigerated Air Dryer from Lingyu is a compact and energy-efficient solution for small to medium compressed air systems. It efficiently removes moisture and maintains a stable dew point, providing clean, dry air for tools, machinery, and production processes.
With its reliable air-cooled design, low power consumption, and easy operation, this dryer series helps improve air system performance, reduce maintenance costs, and protect equipment from moisture-related damage.
The air is pure, no secondary pollution, integrated skid-mounted design, compact structure, stable dew point, remarkable water removal effect.
Stainless steel plate heat exchanger with high heat exchange efficiency and compact structure.
Independent stainless steel steam-water separator with high water separation efficiency, timely separates condensed water and other impurities from compressed air and discharges them out of the machine.
The whole machine is made of stainless steel or aluminum alloy, which will not rust and prevent secondary contamination of compressed air.
Single chip intelligent control, real-time display of evaporation temperature, including over-temperature alarm, electrical fault, high pressure alarm, low pressure alarm and other functions.
Low pressure loss: The precooler is a newly designed annular pipe structure, with three times more pipes than the traditional precooler. The sufficient cross-sectional area of compressed air further reduces the pressure difference, and the pressure loss of the whole machine is less than 0.1 bar;
Frequency conversion energy saving: Brand inverter, frequency conversion range 30Hz~90Hz, by changing the electromechanical frequency of the dryer to match the actual working conditions;
Intelligent control: Standard PLC and touch screen, intelligently control the compressor cooling capacity output by sensing the evaporation load, ensure the machine runs in the best state, and standard RS-485 communication interface.
