High-quality shell material,exquisite appearance design,sophisticated threadprocessing technology;
The differential pressure gauge indicates thetimeto replace thefiter elementat a glance;
The exterior is sprayed withepoxy resin powder to improve durabiityand corrosionresistance;
The casingls marked withthe airflow direction,and thefiter tube head and tubebodyare connected by bayonetypefor easy and quickinstallation andmaintenance;
The flow path is enlargedto reduce pressuredropyReliable automatic draining device;
Using imported filtermaterial,thefiltration accuracy is high.
Our high-performance compressed air filters provide precise particle removal and ultra-low residual oil content for industrial and laboratory applications. Designed for different levels of air purification, these filters ensure clean, dry, and oil-free compressed air, improving the performance and longevity of downstream equipment.
| Grade | Particle Removal | Residual Oil Content |
|---|---|---|
| AO Grade | ≤ 1.0 μm | ≤ 3.0 ppm |
| AX Grade | ≤ 0.01 μm | ≤ 0.05 ppm |
| AA Grade | ≤ 0.1 μm | ≤ 0.1 ppm |
| ACS Grade | ≤ 0.01 μm | ≤ 0.003 ppm |
AO Grade: General industrial air filtration, removes larger particles and oil droplets.
AX Grade: High-purity air filtration for sensitive pneumatic systems.
AA Grade: Fine filtration for precise machinery and instrumentation.
ACS Grade: Ultra-high purity air for critical applications such as electronics, pharmaceuticals, and medical air supply.
ModelCapacity (m³/min)Dimensions (L×W×H mm)Interface DiameterFilter Element ModelYAF-D015AO/AA/AX/ACS1.596×235RC 3/4”(Grade)-015K×1LYAF-D024AO/AA/AX/ACS2.596×235RC 1”(Grade)-024K×1LYAF-D035AO/AA/AX/ACS3.840×310RC 1 1/2”(Grade)-035K×1YAF-D060AO/AA/AX/ACS6.540×410RC 1 1/2”(Grade)-060K×1LYAF-D090AO/AA/AX/ACS10.575×530C 2”(Grade)-090K×1YAF-D120AO/AA/AX/ACS13.575×530RC 2 1/2”(Grade)-120K×1LYAF-D150AO/AA/AX/ACS1775×815RC 2 1/2”(Grade)-150K×1LMAF-D220AO/AA/AX/ACS22240×724RC 3”(Grade)-220K×1LVAF-D240AO/AA/AX/ACS28.5240×724RC 3”(Grade)-240K×1
In Malaysia’s hot, humid, and high-rainfall environment, compressed air systems are more exposed to moisture, particle contamination, and oil carryover. High-performance compressed air filters help improve air cleanliness, protect downstream equipment, stabilise pneumatic performance, and support product quality in industrial and laboratory applications.
These compressed air filters are suitable for applications in Malaysia such as:
– As an air treatment and gas purification manufacturer, we can meet all your compressed air quality and industrial gas needs. This includes various filtering equipment and customized air quality services.
– Our company is always ready to provide explanations. Just share your air quality requirements and we can develop the best system for you.
Need help navigating our compressed air dryer offer? We are always ready to put together the solution that best meets your needs.
